17" x 23" SiC kiln shelf

17" X 23" SILICON CARBIDE KILN SHELF

Part #FS17X

Regular price
CDN$134.40
Sale price
CDN$134.40
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

17" x 23" x 1/2" (430 mm x 585 mm x 13 mm) oxide bonded, silicon carbide shelves (dark grey) are coated on one side with a high-alumina kiln wash. The design incorporates side slits to prolong shelf life by relieving thermal expansion stress. Typical properties and composition are listed below.

Cutting charge $2.00/inch. Larger jobs quoted.

Properties & Composition

 SiC (%): >89

Density (g/cm3): 2.65 - 2.75

Porosity (%): <14

Cold Crushing Strength (Mpa): >90

Cold Modulus of Rupture @ 20 C (Mpa): >40

Hot Modulus of Rupture @ 1400 C (Mpa): >56

Coefficient of Thermal Expansion (25-1400 C): 4.8 x 10 -6

Load Melting Temperature: >1700 C (3092 F)

Maximum Working Temperature: 1400 C (2552F)

Thermal Conductivity @ 1200 C (Kcal/mh C): 14.0
